GS-10 HIGH SPEED TIJ:-
| CAPACITY | 120 m/min |
| Model Name/Number | GS104 |
| Printing Technology | Thermal inkjet technology 2.5 |
| Display | 10 inch capacitive touch screen |
| Ink Type | Water based, solvent based, UV ink |
| Ink Management | Automatically calculate the remaining ink, and estimated print |
| Cartridge Type | 12.7mm, 25.4mm |
| Operation System | Customized Android & Linux |
| CPU | Quad core 1.5 GHz |
| Storage | 3G |
| Print Resolution | 600 dpi, 300 dpi, 150dpi |
| Density | Level 1-6 |
| Speed | Up to 120m/min at 300*600 dpi |
| Throw Distance | 2-5mm recommended |
| Support Pens | 1-4 |
| Max Print Height | 12.7 or 25.4mm(1 pen), 25.4 or 50.8mm(2 pens), 38.1 or 76.2mm(3 pens), 50.8 or 101.6mm(4 pens) |
| Language | English, Spanish, Portuguese,Turkish, Arabic,Farsi,French,Germany, Thai,Korean, Japanese,Russian |
| Print Content | Variable code, variable data, text, date, time, batch number, symbol,QR code,bar code,counter, GS1 |
| Font | Any fonts can be added by yourself |
| Image Format | Jpg, png, bmp, css, web etc. |
| PC Software Format | MS EXCEL,MS Access, SQL2000, SQL2005, SQL2008 |
| Data Format | xls, xlsx, csv, txt |
| Variable Data Format | csv, txt, xlsx, xls |
| Code | Code11,Code16k,Code39,code39+, Code 49,Code93,code128, EAN8,EAN13,EAN14, UPCA,UPCE, INT25,ITF14 |
| External Communication | RS232, USB |
| Controller Size | 264x172x48mm |
| Print Head Size | 130.7×83.76×27.58mm |
| Material | Aluminum |
| Adapter | AC input 100-240v, DC output 32V/5A |
| Interface | 2USB2.0,2 USB3.0,RS232,Gigabit Ethernet, Bluetooth 5.0,encoder, photocell, alarm light |
| Protocol | Customized |
| Working Environment | Temperature 0-45 DegreeC /Humidity 30-80%Rh |
| Minimum Order Quantity | 1 |
Product Description
G10+ High Speed 4 Seperated Heads Online TIJ Printer is the next-generation universal state-of-the-art printing system from TIJ Printers. With a 10′′ touch screen controller that connects to the REACH print head, This Machine is capable of long throw distances and uneven surface applications that are highly adaptable to your packaging printing needs.
Features:
- Can work with 12.7mm and 25.4mm cartridge only by changing the nozzle protector within 1 min without extra fees
- Speed upto 120m/min at 300*600 DPI. Speed may different DPI, Encoder Speed etc.
- Support variable text, barcode, QR code, GS1 etc. Upto 32 code types to meet customers different needs.
- User friendly operating system
- Can connect to scanner, weigher, PLC etc external devices. Ink calculation available.
- Support Multiple Languages, Up To 233 Kinds, You Can Add Input Methods And Fonts By Yourself
